ecoline® + experts = success
Wieland Chase’s formula for a lead-free future encompasses both our ecoline® alloys, which is a portfolio of lead free solutions, and our team of experts.
As a pioneer in lead-free solutions, recycling, and sustainability, Wieland is proud to offer solutions for clean drinking water and pollutant-free products that meet the needs of a wide range of industries. With our team of experts ready to support you every step of the way, you will be ready to secure your lead-free future!
Let’s go lead-free!
New look –
same performance, strength,
and quality
The updated, global e-shield proudly represents our strong portfolio of global and American made ecoline lead-free brass alloys. When you see the e-shield, you can be confident in the highest performing quality, lead-free machinable brass materials that are sustainably made-in-the-USA.
ECO BRASS
Our updated e-shield logo represents ecoline, our comprehensive portfolio of global, lead-free products.
Learn more
ECO BRONZE
Tough, potable water castings, dezincification resistant, wear-resistant, lead-free* bearing and bushing solution
ECO FORGE
Highly forgeable lead-free* alloy that is dezincification and stress corrosion cracking resistant.
Exceeding industry standards
Our ecoline lead-free brass alloy consists of alloys with proven industry performance that are highly machinable, dezincification and stress corrosion cracking resistance. In addition, ecoline alloys are a great choice for customers that demand sustainable solutions for their raw materials.
Economical
With our ecoline alloys, recyclability is not affected in any way. And when changing materials within the same alloy family, the machine does not need to be cleaned.
Efficient
When compared to lead-containing alloys, ecoline alloys have excellent machinability and hot formability at reduced temperatures, making them remarkably efficient.
Experience
When it comes to the transformation from lead-containing to lead-free alloys, Wieland customers can rely on the long-standing and comprehensive expertise of our ecoline experts. With extensive industry expertise as well as detailed process and product knowledge, we find solutions to our customers’ challenges.
The advantages of lead-free ECO alloys
Wieland ecoline alloys provide the performance characteristics you need to achieve exceptional corrosion resistance and to meet potable water compliance required to ensure safe water distribution. With a wide range of shapes and sizes, Wieland has a lead-free solution for your industry.
Physical properties
- Mechanical strength equal to stainless steel
- Wear and corrosion resistance equivalent to commercial bronze
- No lead, no arsenic, and no bismuth added
- Doesn’t become brittle at high temperatures
- Corrosion resistant to chemicals found in water and gas
- Excellent dezincification resistance**
- Electrical conductivity
Compliance
- Compliant with NSF/ANSI 14
- Compliant with NSF/ANSI/CAN 61, Section 9 lead leachate standard
- Compliant with S.3874 Reduction of Lead in Drinking Water Act*
Fabrication properties
- Machinable, forgeable, and castable
- Excellent hot and cold formability
Sustainability
- 100% recyclable
- Certified by GreenCircle Certified for its proven recycled content
* Complies with 0.25% weighted average lead content on wetted surfaces in accordance with Safe Drinking Water Act (SDWA) / Federal Public Law No. 111-380.
** Dezincification: Testing of ECO BRONZE was performed by an independent laboratory to the ISO-6509 testing protocol, and shows ZERO dezincification.
Chemistry Composition
| Alloy: | C69300 |
|---|
| Cu | Si | P | Pb | Fe | Sn | Ni | Mn | Zn |
|---|---|---|---|---|---|---|---|---|
| 73.0-77.0% | 2.7-3.4% | 0.04-0.15% | 0.09% max | 0.10% max | 0.20% max | 0.10% max | 0.10% max | Remainder |
| Alloy: | C69850 |
|---|
| Cu | Si | P | Pb | Fe | Sn | Ni | Mn | Zn |
|---|---|---|---|---|---|---|---|---|
| 67.5-69% | 1.53-2% | 0.04-0.15% | 0.09% max | 0.10% max | 0.20% max | 0.10% max | 0.10% max | Remainder |
| Alloy: | C87850 |
|---|
| Cu | Si | P | Pb | Fe | Sn | Ni | Mn | Sb | Zn |
|---|---|---|---|---|---|---|---|---|---|
| 75.0-78.0% | 2.7-3.4% | 0.05-0.20% | 0.09% max | 0.10% max | 0.30% max | 0.20% max | 0.10% max | 0.10% max | Remainder |
Alloy Comparison Chart Applications
| Name | Alloy | Ingot Form | Rod Form | Applications | Compliance | USA Manufactured |
 ECO BRASS |
Rod: C69300 and Ingot: C87850 | EZ Melt Ingot Engineered Parts |
Rod: Round, Hex, Hex RC, Special Shapes | PEX fittings, stop valves, ball valves, faucets, plumbing fittings and components | NSF/ANSI/CAN 61 compliant NSF/ANSI 14 compliant S. 3874 Reduction of lead in drinking water act compliant |
Yes |
ECO BRONZE |
Rod: C69300 and Ingot: C87850 | EZ Melt Ingot Engineered Parts |
Round, Hex, Hex RC, Special Shapes | Ideal for bearings and bushings, waterworks, valves, fittings and components | NSF/ANSI/CAN 61 compliant NSF/ANSI 14 compliant S. 3874 Reduction of lead in drinking water act compliant |
Yes |
ECO FORGE |
C69850 | Rod | Round Forge | Fromulated for excellent forging for lead-free products | NSF/ANSI/CAN 61 compliant NSF/ANSI 14 compliant S. 3874 Reduction of lead in drinking water act compliant |
Yes |
Alloy Comparison Chart Specifications
| Name | Alloy | Specifications | Minimum Mechanical Properties | ||||
ECO BRASS |
Rod: C69300 | Application: Machine-Forging ASTM: B371 Lengths: 10 to 16 feet Bundle Weights: 1,000-4,000 lbs. |
Diameter (inch) >0.150″ = 0.500″ >0.500″ = 1.00″ >1.000″ = 2.000″ |
Tensile Strength (ksi) 85 75 70 |
Yield Strength (ksi) 45 35 30 |
Elongation (%) 5 10 10 |
|
| Ingot: C87850 | Application: Ingot ASTM: B30 Lengths: 12 inches Ingot Weights: 17 lbs/Ingot, 1,000-4,000 lbs, 2,500 lbs/pallet |
Casting Method Sand Permanent Mold Continuous Cast |
Tensile Strength (ksi) 59 64 65 |
Yield Strength (ksi) 22 32 25 |
Elongation (%) 16 16 8 |
ASTM B584 B806 B505 |
|
ECO BRONZE |
Rod: C69300 | Application: Machine – Forging ASTM: B371 Lengths: 10 to 16 feet Bundle Weights: 1,000-4,000 lbs |
Diameter (inch) >0.150″ = 0.500″ >0.500″ = 1.00″ >1.000″ = 2.000″ |
Tensile Strength (ksi) 85 75 70 |
Yield Strength (ksi) 45 35 30 |
Elongation (%) 5 10 10 |
|
| Ingot: C87850 | Application: Ingot ASTM: B30 Lengths: 12 inches Ingot Weights: 17 lbs/Ingot, 1,000-4,000 lbs, 2,500 lbs/pallet |
Casting Method Sand Permanent Mold Continuous Cast |
Tensile Strength (ksi) 59 64 65 |
Yield Strength (ksi) 22 32 25 |
Elongation (%) 16 16 8 |
ASTM B584 B806 B505 |
|
ECO FORGE |
Rod: C69850 | Application: Forging ASTM: B371 Lengths: 10 to 16 feet Bundle Weights: 1,000-4,000 lbs |
Diameter (inch) >0.150″ = 0.500″ >0.500″ = 1.00″ >1.000″ = 2.000″ |
Tensile Strength (ksi) 60 55 50 |
Yield Strength (ksi) 40 35 30 |
Elongation (%) 5 10 10 |
|
Lead Leachate Performance
CDA sponsored project for independent laboratory measurement of lead leachate
NSF/ANSI/CAN 61 leachate test for all ECO BRASS® and ECO BRONZE® products:
- F1807 Fittings tested for NSF/ANSI/CAN 61 Compliance resulted in lead leachate below the detection limit of 0.5 ppb.
- The ECO BRASS® and ECO BRONZE® family has a Day 3 Q value of 0.25 ppb.
Table 1: Lead (Pb) Composition Determined by ICPMS Following Digestion (mg/kg)
| C36000 | C69850 | C69300 | |
|---|---|---|---|
| Sample 1 | 26,300 | 354 | 658 |
| Sample 2 | 26,900 | 371 | 645 |
| Sample 3 | 26,500 | 355 | 682 |
| Average | 26,566.67 | 360.00 | 661.67 |
| Average (%) | 2.66% | 0.036% | 0.066% |
Table 2: Acceptance Criteria for Lead
| Current Q Value | Proposed Q Value | Proposed 3 Day Level (ug) | |
|---|---|---|---|
| Assembled Product | 5 | 1 | 3 |
| Component | 3 | 0.5 | 1 |
Table 3: Lead Q-statistic Values and Average Day 3 Lead Doses by Alloy Type
| Alloy | C36000 | C37700 | C69850 | C69300 |
|---|---|---|---|---|
| Q Statistic | 2.8 | 0.94 | 0.085 | 0.20 |
| Avg Day 3 Lead Dose (ug) | 7.5 | 4.1 | 0.25 | 0.48 |
